Digital Torque Meter

Digital Torque Meter & Bottle Cap Torque Tester

Stark Embsys manufactures high-precision Digital Torque Meters & Bottle Cap Torque Testers designed for measuring opening and closing torque of threaded bottle caps, screw closures, electrical bulbs, and packaging containers. Featuring rubber-padded clamping pegs, digital peak-hold displays, and bi-directional torque measurement, our meters ensure tight quality control in beverage, pharmaceutical, and cosmetic industries.

Essential for preventing product leakage while ensuring easy consumer opening torque limits according to ASTM and ISO packaging standards.

Digital Torque Meter Stark Embsys

Key Features

Peak Opening Torque Hold

Captures maximum breakaway torque when opening bottle caps or bulb sockets.

Adjustable Clamping Pegs

Rubber-coated pegs accommodate various bottle diameters without scratching containers.

Multi-Unit Display

Selectable torque units in Nm, Ncm, lbf.in, kgf.cm on digital LED/LCD screen.

Technical Specifications

Parameter Specification Detail
Product Model / Category ST-DTM / Cap & Bulb Torque Tester Series
Torque Range Options 0.5 Nm, 2 Nm, 5 Nm, 10 Nm, 20 Nm (5 kgf.cm to 200 kgf.cm)
Accuracy Class ±0.5% Full Scale (F.S.)
Bottle Sample Diameter 15 mm to 200 mm Adjustable Table Pins
Sampling Rate Up to 1000 Hz Peak Capture Rate
Data Output RS232 / USB Interface for PC data logging
Power Supply 230V AC Mains / Rechargeable Battery Operation
Production Capacity & Delivery 50 Units/Month | Ready Stock / 1 to 2 Weeks

Applications

  • Beverage Cap Testing
  • Pharma Vials & Bottles
  • Bulb Socket Testing
  • Cosmetics Packaging
PET bottle and aluminum screw cap torque auditing.
Verifies capping machine torque to prevent carbonated beverage leakage or hard-to-open caps.
Child-resistant pharmaceutical bottle closures.
Tests push-and-turn torque resistance on medicine bottle caps for safety compliance.
Electrical light bulb base cap twisting torque.
Measures torsional strength between glass bulb and metal cap base to prevent separation.
Cosmetic jar, lotion pump, and tube cap testing.
Ensures uniform closure torque across automated bottling and packaging lines.

Why Choose Stark Embsys Digital Torque Meter

  • High-Speed Peak Capture: 1000 Hz sampling rate captures instantaneous cap breakaway torque.
  • Adjustable Bottle Fixture: Fits small pharmaceutical vials up to 2-liter beverage bottles.
  • Bi-Directional Measurement: Evaluates tightening torque and removal torque.
  • NABL Calibration Certificate: Delivered pre-calibrated with master reference torque wrench.
