S-Type Load Cell

S-Type Load Cell (Tension & Compression)

Stark Embsys is a premier manufacturer and supplier of high-precision S-Type Load Cells (S-Beam Transducers). Engineered for dual-mode tension and compression force measurement, our S-Type sensors are manufactured using top-grade tool steel and stainless steel alloys to withstand harsh industrial environments.

Featuring a fully potted strain-gauge bridge with IP67 environmental protection, the S-Type Load Cell delivers superior accuracy, minimal non-linearity, low creep, and long-term stability for material testing machines, hopper scales, and hanging vessel weighing systems.

S-Type Load Cell Stark Embsys

Key Features

Dual Mode Sensing

Supports both Tension (Pull) & Compression (Push) force sensing with precise linearity.

IP67 Protection

Fully potted & sealed against dust, humidity, and liquid ingress for extreme durability.

Steel Construction

Crafted from nickel-plated tool steel / alloy steel with standard threaded connections.

Technical Specifications

Parameter Specification Detail
Product Model / Item Code ST-SBEAM / Item Code: 00435
Rated Capacity Range 50 kg, 100 kg, 200 kg, 500 kg, 1 Ton, 2 Ton, 5 Ton, 10 Ton
Measurement Direction Tension & Compression (Universal)
Rated Output (Sensitivity) 2.0 ± 0.05 mV/V
Combined Error / Non-Linearity ±0.02% to ±0.03% Full Scale (F.S.)
Creep (30 minutes) ±0.02% F.S.
Input / Output Resistance 350 ± 10 Ω / 350 ± 3 Ω
Protection Class Fully Potted & Sealed to IP67
Safe Overload / Ultimate Overload 150% F.S. / 300% F.S.
Excitation Voltage 9 ~ 12 V DC (Maximum 15 V DC)
Operating Temperature Range -20°C to +65°C
Production Capacity & Delivery 10,000 Units/Month | 2 to 3 Weeks Delivery Time

Applications

  • Tank & Vessel Weighing
  • Material Testing (UTM)
  • Crane & Hanging Scales
  • Batching & Conveyors
Ideal for suspended tank, silo, and hopper weighing systems.
Provides suspended load monitoring with tension rod hardware. The IP67 sealing ensures high reliability even in humid chemical or food processing plants.
High precision force transducer for Universal Testing Machines.
Used in Tensile, Compression, Spring, and Material Testing Rigs for continuous force acquisition with low hysteresis and zero drift.
Reliable tension load cell for hanging crane weighers.
Features high safety overload margins (up to 300%) for overhead lifting, foundry cranes, and cable tension measurement.
Automatic bag filling machines and concrete batching plants.
Delivers rapid response speeds for high-speed dynamic batching, automated bagging machines, and belt scale systems.

Why Choose Stark Embsys S-Type Load Cell

  • High Precision & NABL Traceable: Every S-Type load cell is individually tested and calibrated to guarantee minimal non-linearity (±0.02% F.S.) and high accuracy.
  • Heavy Duty & IP67 Sealed: Constructed with nickel-plated tool steel and potted strain gauge sealing for rugged industrial environments.
  • Custom Capacities & Threading: Available in custom capacities from 50 kg to 20 Ton with tailored eye-bolt threads, cable lengths, and output options.
  • Direct Manufacturer Pricing: Get factory-direct pricing, ready stock for standard capacities, and dedicated technical support straight from our New Delhi unit.
